If you're an installer in the United States, you already know that the National Electrical Code (NEC) isn't optional. But if you're a homeowner trying to understand why your installer keeps mentioning "arc fault protection" and "rapid shutdown," the jargon can feel like a wall.

This article breaks down three critical NEC safety requirements for residential solar systems — AFCI, RSD, and GFCI — what they do, why they exist, and how to make sure your system is compliant.

Why NEC Safety Codes Matter for Solar

 Solar panels generate DC electricity whenever sunlight hits them — even during a fire, even during maintenance, even when the grid is down. Unlike standard household circuits that can be shut off at the breaker, a solar array on your roof continues producing voltage as long as the sun is shining.

The NEC addresses this unique hazard through a series of code requirements that have evolved over multiple editions. These requirements protect homeowners, electricians, and especially first responders — firefighters who may need to cut through a roof while live PV conductors are still energized underneath.

The Three Key Safety Features

1. AFCI — Arc Fault Circuit Interrupter

What it does: Detects dangerous electrical arcs in DC wiring and automatically disconnects power before the arc can ignite a fire.

Why it matters: Arcing can occur when wire insulation degrades, connectors corrode, or animals chew through cables. These arcs generate intense heat — often exceeding 6,000°F — and may not draw enough current to trip a standard breaker. Without AFCI, a damaged PV wire can smolder and ignite without any visible warning.

2. RSD — Rapid Shutdown

What it does: Reduces the voltage of PV conductors to safe levels within 30 seconds of activation, protecting firefighters and emergency responders.

Why it matters: When firefighters arrive at a house fire, they often need to ventilate the roof by cutting holes in it. If live solar conductors are running just beneath the roofing material, a single axe strike could result in a lethal shock. Rapid shutdown ensures that within 30 seconds of activation, the voltage outside the array boundary drops to 30V or less, and inside the boundary to 80V or less.

3. GFCI — Ground Fault Circuit Interrupter

What it does: Detects when current is leaking to ground — indicating a fault in the insulation or wiring — and disconnects the circuit before the fault can cause a fire or shock.

Why it matters: Ground faults in PV systems can occur when water penetrates a connector, when a panel frame becomes energized due to damaged insulation, or when mounting hardware pierces a cable. Without GFCI, these faults can persist undetected, creating both fire and electrocution hazards.

NEC Edition Adoption: Know Your Jurisdiction

Not every state is on the same NEC edition. The NEC is updated every three years, but each state adopts it on its own schedule.

For installers: Always verify which NEC edition your local Authority Having Jurisdiction (AHJ) enforces before finalizing your equipment list.

How to Ensure Compliance When Ordering Through Candlon

Select inverters and accessories available through the Candlon platform support these safety features as configurable modules. Here's what to look for:

When you order through Candlon, our team helps you confirm which safety modules are required for your specific jurisdiction, ensuring your system passes inspection the first time.

Common Compliance Pitfalls to Avoid

1. Assuming one RSD solution fits all arrays. String inverters with RSD built in may not meet module-level requirements under NEC 2017+. Module-level power optimizers or microinverters may be needed.

2. Overlooking AFCI for off-grid systems. Even off-grid PV systems on buildings need AFCI if DC voltage exceeds 80V.

3. Ignoring local amendments. Some states and municipalities add stricter requirements beyond the base NEC text.

4. Mixing unmatched safety modules. Using RSD or AFCI components from different manufacturers without verified compatibility can lead to inspection failures.

Build a Code-Compliant System with Confidence

Whether you're an installer navigating NEC requirements across multiple jurisdictions or a homeowner who wants to understand what's protecting your family, knowing the safety requirements is the first step.

Explore our inverter and accessory selection at candlon.com — products are vetted for U.S. code compliance, with safety module options clearly documented.

Need help matching safety modules to your jurisdiction? Our U.S.-based team can help you configure the right AFCI, RSD, and GFCI setup for your project. Contact us today.
